For Honda Accord 2013-2017 LuK Single Mass Flywheel
Price:
$132.16
Ships From:
Rockville Centre, New York, US
Clicking on links to merchants on this site may result in this site earning a commission.
LuK conventional flywheels are dynamically balanced to reduce vibration and improve clutch performance. All new – never remanufactured – every flywheel component is engineered and built to original-equipment specifications, including the ring gear and dowel pins. Single Mass Flywheel by LuK®. LuK conventional flywheels are dynamically balanced to reduce vibration and improve clutch performance. All new – never remanufactured – every flywheel component is engineered and built to original-equipment specifications, including the ring gear and dowel pins. **Specifications:** - Dowel Hole Pattern: 5 - Flywheel Cup Depth or Step Height: -.041 inch - Flywheel Cup Depth or Step Height: -1.05 mm - Ring Gear Mounting O.D.: 10.675 inch - Ring Gear Mounting O.D.: 271.15 mm - Flywheel Thickness \[mm\]: .951 inch - Flywheel Thickness \[mm\]: 24.15 mm - Ring Gear Major Dia.: 11.703 inch - Ring Gear Major Dia.: 297.25 mm - Has Dowel Pins: with Dowel Pins - Ring Gear Thickness: .362 inch - Ring Gear Thickness: 9.2 mm - Bolt Hole Pattern: 2 - Flywheel friction surface outer diameter: 9.173 inch - Flywheel friction surface outer diameter: 233 mm - Flywheel Friction Surface Inner diameter: 5.433 inch - Flywheel Friction Surface Inner diameter: 138 mm - Flange Thickness: .360 inch - Flange Thickness: 9.15 mm - Number of teeth, starter ring gear: 115 - Crank Hole Dia.: .492 inch - Crank Hole Dia.: 12.5 mm - Overall Casting O.D.: 11.254 inch - Overall Casting O.D.: 285.85 mm - Dowel hole diameter: .236 inch - Dowel hole diameter: 6 mm - Crank To Friction Surface: .717 inch - Crank To Friction Surface: 18.2 mm - Centering diameter / dowel hole: 10.000 inch - Centering diameter / dowel hole: 254 mm - Bolt hole PCD clutch pres.plte: 10.000 inch - Bolt hole PCD clutch pres.plte: 254 mm - I.D. for Pilot: 1.476 inch - I.D. for Pilot: 37.5 mm - Bolt hole PCD crankshaft: 2.480 inch - Bolt hole PCD crankshaft: 63 mm **Features:** - Engineered and manufactured to OE specifications - All new components - including ring gear and dowel pins - Perfectly balanced - Precision-machined from premium grade cast iron - Superior quality friction surface - Excellent heat-absorbing capacity - Order from the comfort of your home or office The flywheel is an integral part of a clutch replacement. In today’s tightly packaged clutch systems, flywheels can easily be machined beyond their usable life – a critical flaw that would not be evident until after the clutch is installed. Improper machining can also cause interference, no release and slipping problems. Pairing your LuK RepSet with a new LuK flywheel is a smart, cost-effective alternative to resurfacing. **Replaces Original (OE) Part #:** 221005C8003 Product Video About Us
