80-96 OBS Bronco F150 F-150 Front Wheel Hub Spacer Washer 19 Spline Splined
Price:
$19
Ships From:
Oakland, Tennessee, US
Clicking on links to merchants on this site may result in this site earning a commission.
This listing is for ONE laser-cut splined washer spacer made by Yield Designs that fits 1980-1996 Dana 44IFS (D44IFS) Twin Traction Beam (TTB) 1/2-ton F150 & Bronco by bearing against the end of the spindle. This style & thickness was used from '80~89 with early 5-screw auto hub locks ONLY, but it will also replace the 3-layer spacer used from ~'90-96 with 5-screw & 3-screw auto locks. The C-clip (yellow in the fourth pic; orange in the fifth) is NOT INCLUDED. Nor are the spindle, axle, or original splined spacer (see my other listings). Two are used per vehicle; one for each front spindle. These are being sold EACH, but there is a discount for buying more. Current production run from Aug'25 are clearcoated to prevent flash-rusting before shipment. These are also being sold locally, so the quantity may change, or the listing may end, or a winning bid may be cancelled. If you'd like another shipping option, contact me before buying. No changes can be made after purchase. Check my other listings for more '92-96 Bronco & F-series parts, including 3-layer spacers.
- Item Diameter (Exterior): 1.7"
- Flange Shape: 19 spline
- Item Diameter (Interior): 1.27"
- Material: Abrasion-Resistant (AR) Steel
- Vintage Part: No
- Bore Diameter: 1.14"
- Unit: EACH (1)
- Placement on Vehicle: Front, Left, Right
- Bolt Pattern: 5 x 5.5 in (5 x 139.7 mm)
- Wheel Stud Quantity: 5
- Wheel Stud Size: 1/2"-20
- Brand: Yield Designs™
- Type: Wheel Hub
- Interchange Part Number: 3B458
- Country/Region of Manufacture: United States
- Universal Fitment: No
- Finish: Uncoated (Unfinished)
- Item Width: .17"
- Performance Part: No
